Winding Wires

Elektrisola specializes in fine enamelled wire diameters, starting with 0.008 mm (8 microns), and going up to a diameter of 0.50 mm

Elektrisola offers a wide range of different insulations. Polyurethane has the advantage of easy direct contacting by soldering, while Polyester insulations are more resistant against higher temperatures. Thin top coats as Nylon or Polyamidimide may improve certain desired characteristics like mechanical or chemical strength of the enamelled wire.



Elektrisola produces enamelled wires according to many different specifications. The most important worldwide used specification is IEC, besides NEMA in North America and JIS in Asia.

We are counted among the trustworthy Importers & Suppliers of Triple Insulated Wires in the domestic market. The company has installed a physical facility for manufacturing these wires in several grades and ratings for furnishing variegated demands of the buyers. Further, our Triple Insulated Wires are obtainable in different packaging sizes. Our prices are also quite nominal.



The Benefits For Triple Insulated Wire are :

• Rolled Coil easily.
• High voltage insulation, could save insulating tape, insulating interlayer.
• Eliminates the need for the creepage margin.
• Superior wear resistance for high speed automatic Transformer winding line.
• Three layers of insulation protection, there is no pinhole phenomenon.
• Self Solderable So No Striping Requird.
• Size of The Transformer Can be Cut down to 30-50% Due To No Requirement of Interlayer Tapes.
• Save copper due to less number of turns required after eliminating insulating tape & interlayer.
• Intercourse Wear More Than 250 Times.
• Triple insulated wire Ranges From 0.16 TO 1.00 mm.

Features

• Consist of three layers of insulation. Completely isolate the primary winding from the secondary winding of transformers.
• Greatly reduce the size and weight of transformers.
• Greatly improve the eficiency of the transformers by reducing the distance between coils.
• Allow to wind directly on the top of enameled wires. Eliminate the interleaved insulation tapes, barriers and insulating sleeves.
• Solderable without the need of insulation pre-stripping.
• Can be fast coiled by using an Automatic Coiling Machine.
• Thermal Resistance Class B (130 C) and Class F (165 C) are available.
• Self-Bonding type has a self-bonding layer that covers the outer surface. The bobbin can be eliminated and the size and weight or transformers can be further reduced.
• Litz wire type has high frequency resistance that can sharply reduce the power losses caused by skin and proximity effect and is suitable for high frequency transformers.

The Advantages of Triple Insulated Wire are :

• Rolled coil easily.
• High voltage insulation, could save insulating tape, insulating interlayer.
• Superior wear resistance for high speed automatic Transformer winding line.
• Three layers of insulation protection, there is no pinhole phenomenon.
• Self Solderable So No Striping Required.
• Size Of The Transformer Can Be Cut down To 20-30% Due To No Requirement Of
• Interlayer Tapes

• Save copper due to less number of turns required after eliminating insulating tape &
• interlayer.
• Intercourse Wear More Than 250 Times

• Triple insulated wire comes in three different temperature gradient :

  • Class E to 120 C
  • Class B to 130 C
  • Class F to 155 C

• Triple insulted wire Ranges From 0.16 TO 1.0 mm.

<p>We are reckoned as the prime Importer and Supplier of the ELEKTRISOLA brand <strong>Litz Wire</strong>, based in India. Our Litz Wire is made up of numerous strands of enamelled magnet wire, stranded together. The Litz Wire is used for wide industrial applications and thus it is highly acclaimed by the widespread clients. Our Litz Wire can be availed at the market leading prices.<br /><br /><strong>Applications :</strong></p> <ul> <li>Proximity switches</li> <li>Repeating coils</li> <li>Magnetic loading</li> <li>Power supply units</li> <li>Transformers and choking coils</li> <li>Identification systems</li> <li>Ultrasonic generators</li> <li>Deflection yokes</li> <li>Inductive heating elements</li> <li>Fluorescent lamp ballast</li> <li>Hearing aids</li> </ul> <p><br /><strong>Advantages :</strong></p> <ul> <li>Active customer support nearby</li> <li>High degree of process control</li> <li>Worldwide presence</li> <li>Flexibility and speed in the complete business process</li> <li>Complete production process out of one hand</li> <li>Individual configuration</li> <li>Topical and consumption near disposition strategies</li> </ul>

Fully Insulated Wire has high thermal class and zero-defect strengthened insulation. It finds extensive usage in automotive industry. We are one of the prominent Importers and Suppliers of Fully Insulated Wire. It is procured from the most reliable sources of the market. When it comes to delivery, we make all arrangements for quick shipment of Fully Insulated Wire. It can be obtained from us in small as well as bulk quantities.

Our company’s name figures in the list of reputed Importers and Suppliers of Self Bonding Wires. The Self Bonding Wires we make available are manufactured in compliance with set industrial norms. In order to meet the bulk and urgent requirements of the buyers, we maintain a large stock of the Wires in our state-of-the-art warehouse. Buyers can obtain the Wires at reasonable rates from us.
